17 Watt 48 Inch T8 LED; 35K/40K/50K CCT Selectable; Ballast Bypass with Battery Backup; G13 Base; (X3QDX)

Image may not reflect selected features

No Image
Available

17 Watt 48 Inch T8 LED; 35K/40K/50K CCT Selectable; Ballast Bypass with Battery Backup; G13 Base;

BASE PRICE:

/ / 1

($88.50 / 1)

WAS

Call for Price

Item #:

X3QDX

Dimensions:

Width: 1.13"

Finish Family:

White

Availability:

Manufacturer has 1045 items available.

Description

Details

Downloads

17 Watt 48 Inch T8 LED; 35K/40K/50K CCT Selectable; Ballast Bypass with Battery Backup; G13 Base; 120-277 Volt

Category:

Lamps

Subcategory:

LED Lamps

Lumens:

1601-2600

Kelvin:

3501-4000

Category:

LED

Sub-Category:

LED T8

Volts:

120V-277V

Bulb Hours:

50000

Bulb Kelvin:

3500K/4000K/5000K

Bulb Shape:

Diameter:

1.13

EA Length:

48.11

Harmonized Codes:

8539.52.0051

Length:

47.78

Lumens:

2100L/2300L/2200L

Shap Carton Width:

2.05

Ship Carton Height:

1.34

Ship Weight:

1.08

Warranty:

5 Year Limited - T8 LED Bulbs - Ballast Bypass

Weight:

0.99

Additional Info:

5 Watts and 700 Lumens in Emergency Mode

BAA Compliant:

Ballast Bypass Direct:

Ballast Bypass

Ballasting Requirements:

Ballast Bypass

Battery Chemistry:

Lithium-ion (Li-ion)

Beam Spread:

140

Bulb ANSI Base:

G13

Bulb Base:

Medium Bi Pin

Bulb Finish:

White

Burning Position:

Horizontal

Carton Cubic Feet:

0.0765

Cartons Per Unit:

CCT Selectable:

Yes

CEC:

Exempt - Base Not Regulated

CEC Terse:

Lawful for sale in California

CEC Web Text:

Lawful for sale

Color Temprature:

Neutral White to Natural Light

Country Of Origin:

China

CRI:

DLC Approved:

Yes

DLC Classification:

Standard

DLC ID:

S-MASCZT

DLC Primary Use:

Internal Driver/Line Voltage (UL Type B) Lamps

Efficacy:

123.53/135.29/129.41 LPW

Enclosed Fixture Use:

Yes

Enclosure Rating:

Not for use in fully enclosed vapor tight fixtures

FCC Compliant:

Yes

Feature 1:

Provides up to 90 minutes of illumination during power outages

Feature 2:

Battery On/Off switch conserves battery after installation

Feature 3:

Integrated aluminum heatsink to promote heat dissipation

Feature 4:

Features ColorQuick technology, allowing for easy selection of CCT at installation

Feature 5:

5 Year Warranty

Flourescent Equivalent:

32W

Has Driver:

Yes

Has Emergency Battery:

Yes

Housing Color:

White

Incandescent Equivalent:

90W

Indoor Outdoor:

Indoor

Installation Notes:

Not for use in vapor tight fixtures. Maximum Mounting Height: 13 Feet

IOT Enabled:

IP Rating:

IP20

JA8 Compliant:

Lamp Ballast Type A/B/C:

Type B

Lamp End Type:

Single Ended

Lamp Filament:

LED

Lens Finish:

Frost

Lens Material:

Polycarbonate (PC)

Location Rating:

Damp

Material:

Aluminum

Nominal Length:

NSF Approved:

Yes

Operating Frequency:

60Hz

Operating Temp:

-20C (-4F) to +45C (+113F)

Pack Type:

Box

Power Factor:

0.9

Quantity In Pack:

R9 Value:

RoHS Compliant:

Yes

Romance Copy:

Satco|Nuvo's T8 lamps with Battery Backup are the logical choice for commercial installations. Providing up to 90-minutes of illumination in the event of a power failure, these lamps are ideal for use where backup lighting is essential. Available in 15

SDS class:

Lithium_Ion_Battery

Shatter Proof Text:

Yes

Short Description:

17T8/LED/48-CCT/BB/BP

Specification Notes:

Height at switch: 1.30 Inches; Work time after power failure: 90 Minutes; Battery Recharge Time is 24 hours

Style:

Utility

Surge Protection:

Built-in surge protection - 1KV

Technology:

LED

Title 20 Compliant:

Title 24 Compliant:

Total Harmonic Distortion:

<25%

Tube Guard Use:

Wattage Selectable:

Watts:

17W
